1.Moulding Silicone characteristics: Used for molding machine single molding apparel LOGO or with the dispensing machine molding silicone label, easy to release the mold, strong firmness.
2. Operating instructions:
A.Mix the silicone XG-360W and additives XG-360WB and color paste according to the proportion, pour into the LOGO mold, fill the mold.
B.Then put them into the vacuum machine vacuum, a few minutes after taking out the mold with a scraper to scrape the silicone, excess silicone put back to save the LOGO outside can also be wiped clean with a rag.
C.The mold inverted into the fabric, will be adjusted in advance of the mold machine to press its(Temperature: 180 degrees above the mold temperature, button temperature 50-60 degrees, heating time 8-18 minutes or so)
D.Separate the fabric and LOGO mold, The finished product is displayed on the fabric.
Attention:
High-temperature molds in the addition of vulcanizing agent into the solid silicone raw materials through the vulcanizing machine to apply pressure, high-temperature vulcanization into solidified molding, molded silicone hardness is usually 30 ° C - 70 ° C. Raw materials with the color paste in accordance with the Pantone color card No. to adjust the color, the shape of the mold determines the shape of the molded silicone products.
3.Parameters: high and low temperature resistance, waterproof, non-toxic, tasteless, environmentally friendly, easy to release the mold, strong firmness.
4.FAQ：
Q1. Is there technical after-sales service?
A: Yes, we will provide professional technology and provide samples.
Q2. Difference between moulding silicone and embossed silicone
A: Moulding silicone is used for single-molded apparel logos, and embossed silicone is used for apparel embossing process to do flower shaping. Both of them have strong firmness.
Q3. Whether the product is qualified?
A: Our products, strict quality control, the implementation of NIKE RSL, ADIDAS A-01 standards, through the REACH and ZDHC Level3 related testing, and access to OEKO-TEX-ECO Passport certification.
